Siemens 6ES7223-1BL32-0XB0 Digital Input Output module SM1223
SIMATIC S7-1200, Digital I/O SM 1223, 16 DI/16 DO, 16 DI 24 V DC,
Sink/Source, 16 DO, transistor 0.5 A
Siemens 6ES7223-1BL32-0XB0 Digital Input Output Module SM1223
Communication module integration process
The integrated PROFINET interface is used for programming, HMI communication, and communication between PLC. In addition, it also supports communication with third-party devices through open Ethernet protocol. The interface has an RJ45 connector with auto-cross-over capability, providing data transfer rates of 10/100 Mbit/s. It supports up to 16 Ethernet connections and the following protocols: TCP/ IPNative, ISO-ON-TCP, and S7 communication.
The SIMATIC S7-1200 CPU can add up to three communication modules. RS485 and RS232 communication modules provide connections for point-to-point serial communication. The extended instruction or library function, USS driver protocol, Modbus RTU master station, and slave station protocols are used in the configuration and programming of the communication, which is all included in the SimaticStep 7 Basic engineering configuration system.
High-speed input
The SIMATIC S7-1200 controller comes with up to six high-speed counters. Three of the inputs are 100kHz and three are 30kHz for counting and measurement.
High-speed output
The SIMATIC S7-1200 controller integrates two 100kHz high-speed pulse outputs for the stepper motor or to control the speed and position of the servo drive. Both outputs can output PWM signals to control motor speed, valve position, or duty cycle of heating elements.
| Product name | Siemens 6ES7223-1BL32-0XB0 Digital Input Output module SM1223 |
| Manufacturer | Siemens |
| Brand | Siemens |
| Series | S7-1200 |
| Part Number | 6ES7223-1BL32-0XB0 |
| Product Type | Digital Input Output module |
| Supply voltage | 24V |
| Input current | from backplane bus 5 V DC, max. 185 mA |
| Power loss | Power loss, typ. 4.5 W |
| Size | 70*100*75mm |
| Weight | 310g |
PLC has been widely used in various industries such as steel, petroleum, chemical industry, electric power, building materials, machinery manufacturing, automobiles, textiles, transportation, environmental protection, culture and entertainment at home and abroad.
The usage can be roughly classified into the following categories:
1. Logic control of the switch
2. Analog control
3. Motion control
4. Process control
5. Data processing
6. Communication and networking
Online support and Video technical support.
